120 mm mortar bomb
Practice
DESCRIPTION
120 mm Practice Mortar Bomb is used for training purposes with 120 mm smooth-bore mortars. It replicates the size and ballistic properties of a live high-explosive round without an explosive payload. The bomb is suitable for realistic instructional use under all environmental conditions and ensures safe storage and handling.
Key Parameters
CALIBER
120 mmMAXIMUM RANGE (INCREMENT)
5800 mMAXIMUM RANGE (LONG RANGE)
7100 mOPERATING TEMPERATURE RANGE
-50°C to +50°CSHELF LIFE
10 yearsTechnical Data
LENGTH OF MORTAR BOMB (FUZED)
673 mmWEIGHT OF MORTAR BOMB
16.07 ±0.050 kgElements of Mortar Bomb
FUZE
DummyBODY
Cast ironNUMBER OF CHARGES
1 + 6 Increment or Long Range ChargesBallistic Data
MUZZLE VELOCITY (MAX)
272 m/sMAX PRESSURE
1030 / 1300 kgf/cm²
