14.5×114 mm cartridge
API-T bullet (57-API-T-561S)
DESCRIPTION
The cartridge is intended for target designation, fire correction, and ignition of flammable targets. It effectively engages lightly armored ground targets at distances up to 1,000 m, emplacements and targets behind light barriers, infantry and vehicles at distances up to 2,000 m, and low-flying aerial targets at altitudes up to 2,000 m. The cartridge is fired from KPV, KPVT, PKP, and SKP machine guns, as well as IST-14.5 anti-materiel rifles. The bullet tip is painted red and violet.
Key Parameters
CALIBER
14.5x114 mmMUZZLE VELOCITY
995-1015 mmACCURACY (R₅₀), CM AT 100 M
≤7 cmMAX MEAN GAS PRESSURE, MPA (KGF/CM²)
3300 (323.6)BULLET WEIGHT
58.5 – 60.5 gPOWDER CHARGE WEIGHT
30 gCARTRIDGE WEIGHT
178-188 gCARTRIDGE LENGTH
156⁻¹.⁵ mmTRACER RANGE
2000 mARMOR PENETRATION AT 20° (20 MM PLATE), M
100 mGRADE POWDER
5/7CASE MATERIAL
Steel
